YSLYCY-JZ and YSLYCY-OZ are shielded flexible control cables compliant with European standards (e.g., VDE 0250), used for signal and power transmission in industrial automation and machinery. Both feature fine-stranded copper conductors, PVC insulation, oil-resistant PVC sheaths, and tinned copper braid shielding for electromagnetic interference (EMI) protection, suitable for indoor dry/wet environments, oil-resistant but not UV-resistant, avoiding prolonged outdoor use. The key difference is: YSLYCY-JZ includes a green/yellow earth conductor, while YSLYCY-OZ does not.
Standard:VDE0281
Ratedvoltage:300/500 V (Uo/U)
operatingtemperature:-5℃~ 70 ℃
CPRstandard：EN60332，EN50575
blackwithnumberprinting, withonecoregreen-yellow (JZ), without (OZ)
| Number of cores x nominal cross-section (mm²) | Max. conductor resistance (Ω/km) | Outer diameter (mm) appr. | Total weight (kg/km) appr. |
| 2x 0.5 | 39 | 5.4 | 41 |
| 3 x 0.5 | 39 | 5.7 | 50 |
| 4 x0.5 | 39 | 6.1 | 59 |
| 5x 0.5 | 39 | 6.6 | 72 |
| 7 x0.5 | 39 | 7.1 | 85 |
| 10 x0.5 | 39 | 9.1 | 123 |
| 12 x0.5 | 39 | 9.4 | 138 |
| 14 x0.5 | 39 | 10.0 | 159 |
| 16 x0.5 | 39 | 10.5 | 175 |
| 21x 0.5 | 39 | 12.5 | 230 |
| 25x 0.5 | 39 | 13.2 | 260 |
| 30 x0.5 | 39 | 15.3 | 363 |
| 34 x0.5 | 39 | 16.3 | 420 |
| 40 x0.5 | 39 | 17.3 | 465 |
| 50 x 0.5 | 39 | 19.6 | 575 |
| 61 x0.5 | 39 | 20.8 | 675 |
| 2 x 0.75 | 26 | 6.0 | 53 |
| 3 x0.75 | 26 | 6.1 | 60 |
| 4 x0.75 | 26 | 6.6 | 73 |
| 5 x 0.75 | 26 | 7.6 | 95 |
| 7 x0.75 | 26 | 7.9 | 110 |
| 8 x0.75 | 26 | 8.8 | 138 |
| 10 x0.75 | 26 | 10.0 | 155 |
| 12 x0.75 | 26 | 10.3 | 175 |
| 16 x0.75 | 26 | 11.5 | 220 |
| 21x 0.75 | 26 | 13.6 | 290 |
| 25x 0.75 | 26 | 14.4 | 325 |
| 44x 0.75 | 26 | 19.2 | 600 |
| 50 x 0.75 | 26 | 20.6 | 695 |
| 61 x 0.75 | 26 | 23.0 | 720 |
| 2x 1 | 19.5 | 6.3 | 56 |
| 3x 1 | 19.5 | 6.6 | 70 |
| 4x 1 | 19.5 | 7.2 | 85 |
| 5 x 1 | 19.5 | 8.0 | 105 |
| 7x 1 | 19.5 | 8.7 | 130 |
| 11 x 1 | 19.5 | 11.0 | 190 |
| 12 x 1 | 19.5 | 11.3 | 215 |
| 14 x 1 | 19.5 | 12.2 | 250 |
| 16 x 1 | 19.5 | 12.8 | 280 |
| 18 x 1 | 19.5 | 13.5 | 315 |
| 21x 1 | 19.5 | 15.0 | 360 |
| 25x 1 | 19.5 | 16.0 | 410 |
| 30 x1 | 19.5 | 17.6 | 530 |
| 34 x1 | 19.5 | 19.1 | 604 |
| 50 x 1 | 19.5 | 22.6 | 849 |
| 2x 1.5 | 13.3 | 6.7 | 67 |
| 3 x 1.5 | 13.3 | 7.0 | 85 |
| 4 x1.5 | 13.3 | 7.9 | 106 |
| 5x 1.5 | 13.3 | 8.6 | 130 |
| 7 x1.5 | 13.3 | 9.2 | 165 |
| 8 x1.5 | 13.3 | 10.5 | 215 |
| 10 x1.5 | 13.3 | 12.1 | 245 |
| 12 x1.5 | 13.3 | 12.5 | 280 |
| 14 x1.5 | 13.3 | 13.1 | 315 |
| 16 x1.5 | 13.3 | 13.8 | 350 |
| 18 x1.5 | 13.3 | 14.5 | 395 |
| 21 x 1.5 | 13.3 | 15.6 | 440 |
| 25 x 1.5 | 13.3 | 16.7 | 510 |
| 32 x1.5 | 13.3 | 22.3 | 817 |
| 34 x1.5 | 13.3 | 23.3 | 874 |
| 44 x1.5 | 13.3 | 26.5 | 1139 |
| 50 x 1.5 | 13.3 | 27.8 | 1269 |
| 61 x1.5 | 13.3 | 29.4 | 1490 |
| 2x 2.5 | 7.98 | 7.9 | 95 |
| 3 x 2.5 | 7.98 | 8.4 | 125 |
| 4 x2.5 | 7.98 | 9.1 | 155 |
| 5x 2.5 | 7.98 | 10.1 | 190 |
| 7 x2.5 | 7.98 | 11.0 | 245 |
| 10 x2.5 | 7.98 | 14.1 | 350 |
| 12 x2.5 | 7.98 | 14.6 | 405 |
| 18 x2.5 | 7.98 | 18.2 | 570 |
| 50 x 2.5 | 7.98 | 32.9 | 1898 |
| 3x 4 | 4.95 | 9.9 | 175 |
| 4x 4 | 4.95 | 10.8 | 220 |
| 5 x 4 | 4.95 | 11.7 | 270 |
| 7x 4 | 4.95 | 14.8 | 440 |
| 2x 6 | 3.3 | 10.5 | 180 |
| 4x 6 | 3.3 | 12.5 | 310 |
| 5 x 6 | 3.3 | 13.6 | 385 |
| 7x 6 | 3.3 | 17.3 | 604 |
| 4 x10 | 1.91 | 16.3 | 523 |
| 5 x 10 | 1.91 | 17.9 | 637 |
| 7 x 10 | 1.91 | 24.4 | 1079 |
| 4 x16 | 1.21 | 23.5 | 954 |
| 5 x 16 | 1.21 | 26.2 | 1217 |
| 7 x 16 | 1.21 | 28.8 | 1587 |
| 4 x25 | 0.78 | 23.0 | 1128 |
| 5 x 25 | 0.78 | 25.4 | 1384 |
