(UTP) Data Transmission Cable for Local Networks,
Unscreened, CAT 5e
Conductor material Solid bare copper
Core insulation Polyvinylchloride (PVC)
Outer sheath Polyvinylchloride (PVC),grey
Standard CAT 5e
TIA/EIA 568 B,
ISO/IEC 11801 2. Output
EN 50173-1
IEC 708-1 (core identification)
Technical Data:
Temperature range -0°C TO +60°C （moved）
Loop impedance 19,0 [Ohm/100m]
Capacity max. 50[nF/km]
Nom. Velocity of propagation NVP nom. 77,0
Attenuation 100,0 [Ohm]
Capacity coupling 150 [pF/100m]
Insualtion resistance 5 [GOhm/km]
Application:
In the horizontal wiring as an installation cable for the transfer in cable canals as well as in pipes within telecommunication installations and data systems.
Area of application: IEEE 802.3:10 Base T, 10 Base T Ethernet, 100 Base T, 1000 Base T, FDDI, ISDA, ATM.
