Communication Cable Interbus-22
Conductor material Fine-stranded bare copper
Core insulation Polyethylene (PE)
Layer Plastic foil
Braid Tinned copper wires
Outer sheath Polyvinyl chloride (PVC), magenta
Standard DIN 47100or factory standard (core identification)
Information: More types and constructions of enquiry.
Technical data:
Temperature range -5°C TO +60°C （in motion ）
-0°C TO +50°C （not moved ）
Conductor resistance Max. 83 [Ohm/km]
Attenuation 100 [Ohm]
Mutual capacitance Max. 50
Application:
The circuit can connect different components within automation devices. The twisted cores are also the basic element. Because all bus components are connected in that way, costly parallel wiring can be avoided.
