Conductor23AWGX4P
core insulation HDPolyethylen
PVC-sheath or with halogen free sheath
Standards: UL 444
ISO/IEC 11801 2.Edition
TIA/EIA 568-B.2
IEC 61156-5
Technical data:
Temperature range -20°C TO +75°C （moved）
| Conductor Resistance | Max 72.2ohm/km at 20°C |
| Rated Voltage | Max 300Volts |
| DC Resisitance Unbalance | Max5% |
| Pair-to-Ground CapacitanceUnbalance | Max3300pF/km |
| Characteristic Impedance | 100+/-15OHM |
| Nominal Velocity of Propagation (%) | 67~69 |
| Propagation Delay | Max 536ns/100m |
| Delay Skew | Max 40ns/100m |
